Datasensing SH4 STANDARD MUTING - Test and Range Selection

DIP SWITCHES
PRODUCT REFERENCE GUIDE 37
SH4-XX-XXXX-SM-8 Dip Switches Settings
SH4-XX-XXXX-SM-8-5 Dip Switches Settings
FUNCTION DIP SETTINGS (DEFAULT IN BOLD)
Partial Muting 1
OFF: Total Muting
ON: Partial Muting
Code 2 - 3
OFF - OFF: no code
OFF - ON: code 1
ON - OFF: code 2
ON - ON: not used (Configuration Failure if set)
EDM 4
OFF: Disabled
ON: Enabled
Restart Mode 5
OFF: Automatic
ON: Manual
Muting Direction 6
OFF: T
ON: L
Muting Timeout 7
OFF: 10 min
ON: infinite
Muting Filter 8
OFF: 100ms muting filter
ON: no muting filter
FUNCTION DIP SETTINGS (DEFAULT IN BOLD)
Override Trigger
1
1. When Restart Mode is Manual a RESTART signal is requested at the end of Override sequence.
1
OFF: Level
ON: Edge
Code
2 - 3
OFF - OFF: no code
OFF - ON: code 1
ON - OFF: code 2
ON - ON: not used (Configuration Failure if set)
EDM
4
OFF: Disabled
ON: Enabled
Restart Mode
5
OFF: Automatic
ON: Manual
Muting Direction
6
OFF: T
ON: L
Muting Timeout
7
OFF: 10 min
ON: infinity
Muting Filter (100ms)
8
OFF: 100ms muting filter
ON: no muting filter
