USER INTERFACE DIALOGUE
62 SH4 STANDARD MUTING
RX Side dialogue
ESPE
WORKING MODE
INDICATION LED CONFIGURATION
Alignment
NOTE: the LEDs F and L
change color according to
the anti-interference code
set:
BLUE: NO CODE
RED: CODE1
GREEN: CODE 2
Not aligned
Not aligned
Only first sync aligned
Not aligned
Only last sync aligned
Aligned
Minimum Signal Level
Aligned
Medium Signal Level
Aligned
Maximum Signal
Level
Module signal status
(from 2
nd
module)
Good Signal on
modules, no optics
intercepted
Low Signal on
modules, no optics
intercepted
At least one optic
intercepted on
modules with
blinking red light
(eg.) Modules with
different signal
levels
Normal Operation
Manual Restart Only
Manual Restart
configured
Interlock, free
beams, restart
required
Normal Operation EDM Active
1
st
module
2
nd
module N
th
module
