Datasensing SH4 STANDARD MUTING - Pairing Table

MODELS
PRODUCT REFERENCE GUIDE 77
Pairing table
SH4-2-0500-SM-8 957920139 SH4-2-0500-SM-8-5 957920135
BODY
PROTECTION
500
SH4-3-0800-SM-8 957920140 SH4-3-0800-SM-8-5 957920136 800
SH4-4-0900-SM-8 957920141 SH4-4-0900-SM-8-5 957920137 900
SH4-4-1200-SM-8 957920142 SH4-4-1200-SM-8-5 957920138 1200
MODEL
SINGLE CONNECTOR
ORDERING
NUMBER
MODEL
DUAL CONNECTOR
ORDERING
NUMBER
RESOLUTION
PROTECTED
HEIGHT (mm)
PAIR MODEL RECEIVER MODEL EMITTER MODEL
SH4-14-XXXX-SM-8 SH4-14-XXXX-SM-R-8 SH4-14-XXXX-T-5
SH4-14-XXXX-SM-8-5 SH4-14-XXXX-SM-R-8-5 SH4-14-XXXX-T-5-5
SH4-30-XXXX-SM-8 SH4-30-XXXX-SM-R-8 SH4-30-XXXX-T-5
SH4-30-XXXX-SM-8-5 SH4-30-XXXX-SM-R-8-5 SH4-30-XXXX-T-5-5
SH4-2/3/4-XXXX-SM-8 SH4-2/3/4-XXXX-SM-R-8 SH4-2/3/4-XXXX-T-5
SH4-2/3/4-XXXX-SM-8-5 SH4-2/3/4-XXXX-SM-R-8-5 SH4-2/3/4-XXXX-T-5-5
