Datasensing SH4 STANDARD MUTING - SH4-X-XXXX-SM-8 Models

OVERRIDE
PRODUCT REFERENCE GUIDE 57
SH4-X-XXXX-SM-8 models
Override can be activated by a single input, provided that a specific signal pattern is
respected.
The Override input (pin 1) is shared with EDM feedback and Restart.
Two different way of starting OVERRIDE are provided:
• “Override at Startup” on page 58
• “Override at Runtime” on page 59
1
2
White
Brown
Test
24Vdc
KM1
KM2
Restart/
Override
