SH4 STANDARD MUTING
ANTI INTERFERENCE CODING
Anti-Interference Coding function implemented in SH4 devices allows the user to install
two light curtains very close each other without that an interference occurs; this allows
the devices to remain in normal operation condition.
Configuration RX
On RX unit set the Dip switch according to the chosen configuration:
Configuration TX
TX unit will select emission code based on CODE input connection (pin 4, M12-5 TX con-
nector) at light curtain startup:
NOTE: For correct light curtain operation both emitter and receiver unit
must be configured with the same Coding setting.
Code
2 - 3
OFF - OFF: no code
OFF - ON: code 1
ON - OFF: code 2
ON - ON: not used
1
1. Configuration Failure if set
CODE INPUT CONNECTION
AT STARTUP
EMISSION CODE
COM CODE1
0V/FLOAT NO CODE
24V CODE 2
