SH4-XX-XXXX-SM-8-(5) MODELS
PRODUCT REFERENCE GUIDE 63
Normal Operation
OSSD OFF
CODE1
CODE2
NO CODE
Partial Muting
On models longer than 1200 only even modules blinking yellow
Override allowed
Normal Operation
OSSD ON
Minimum Signal
Level
Good Signal Level
Maximum Signal
Level
Muting Active
Override Active
Configuration
Reset Default
Performed
Failure
(Lockout)
Power Supply
Failure
F11
OSSDs failure
F22
Microprocessor
Failure
F33
Optics Failure
EDM Failure
Restart Failure
F1122
Cascade Failure
F2233
Configuration
Failure
F20
Lamp Failure
F1133
Input Failure
