Datasensing SH4 STANDARD MUTING - Page 75

SH4-X-XXXX-8-(X) MODELS
PRODUCT REFERENCE GUIDE 67
Normal Operation
OSSD OFF
At least one beam
intercepted
Override allowed
Partial Muting
Active.
At least one beam
outside muting
zones intercepted
Normal Operation
OSSD ON
Muting Active
Override Active
Configuration
Reset Default
Performed
Failure
(Lockout)
Power Supply
Failure
FER
OSSDs failure
F1
Microprocessor
Failure
F2
Optics Failure
FE
EDM Failure
FR
Reset/Restart Failure
F12
Configuration
Failure (Dip switch)
F12E
Lamp Failure
Not intercepted beams
or intercepted beams
in muting zone.
Intercepted beams
outside the muting
zone.
All
beams
All
beams
First
module
