dataTaker DT80 - Page 268

UM-0085-B09 DT80 Range User Manual Page 268
RG
Section Name
Key Name
Legal Values
Factory Default
Comment
WIFI
COEX_MODE WLAN
WLAN
Selects WIFI module operation mode
defining protocol stacks loaded.
Currently, only WLAN mode is
supported.
SECURITY_MODE
OPEN,
PSK_WEP,
PSK_WPA,
PSK_WPA2
PSK_WPA2
Defines security mode being used by
logger’s WIFI interface.
PSK
string
DATATAKER
Pre-Shared Key Secret
SSID
string
DT80S4-AP
WIFI Service Set Identifier (SSID).
HIDDEN_SSID YES,NO
NO
Enables hiding SSID during network
scan for Access Point Mode.
IP_ADDRESS
IP ADDRESS,
AUTO
AUTO
IP Address for the WIFI Interface in
Client mode. When AUTO selected IP
Address and subsequent parameters
will be retrieved via DHCP.
GATEWAY
IP ADDRESS
192.168.0.1
IP Address of the Gateway
SUBNET_MASK IP ADDRESS
255.255.255.0
Subnet mask for the interface IP
Endpoint
METRIC
decimal
30
WIFI Interface Metric
DNS_SERVER1
IP ADDRESS
NONE
Primary DNS Server Address
DNS_SERVER2
IP ADDRESS
NONE
Secondary DNS Server Address
WLAN_AGGREGATION YES,NO
NO
Enable WLAN Aggregation for the WIFI
Interface
ANTENNA_SELECT INT,EXT
EXT
Select what antenna to use on WIFI
Module: Internal or External.
FREQ_BAND
2_4GHZ,
5GHZ,
DUAL_BAND
2_4GHZ
Select frequency bands being used by
WIFI Module: 2.4Ghz, 5GHz, and Dual
Band (2.4GHz and 5GHz
simultaneously). Availability of particular
bands depend on the module being
used in the unit.
ENCRYPT_MODE NONE,TKIP,CCMP
CCMP
Defines encryption algorithm:
None – no encryption;
TKIP – Temporal Key Integrity Protocol;
CCMP – Counter Mode Cipher Block
AP_CHAN_NO 0-165
1
Access Point Channel Number defines
a channel being used in the Access
Point Mode by the module.
BEACON_INTERVAL
100-1000
100
Beacon Interval for WIFI Interface
DTIM_PERIOD 1-255
1
Delivery Traffic Indication Message
(DTIM) Interval
MAX_STA_SUPPORT 0-4
4
Maximum number of client stations
supported by the module configured in
the Access Point Mode.
DHCP_SRV_ENABLE YES,NO
YES
Enable DHCP Server for the interface in
Access Point Mode.
DHCP_RANGE_START_IP IP ADDRESS
192.168.0.2
DHCP Server leasing range start
address
DHCP_RANGE_END_IP IP ADDRESS
192.168.0.50
DHCP Server leasing range end
address
DHCP_LEASE_TIME 10-4294967293
86400
IP Address leasing time by DHCP
Server in seconds
SMTP_SERVER
string
NONE
SMTP Server Name
SMTP_ACCOUNT
string
NONE
SMTP Account Name
SMTP_PASSWORD
string
NONE
SMTP Account Password
SMTP_PORT
0-65535
25
SMTP Port Number
RETURN_ADDRESS
string
Your.Logger@dat
ataker.com
Return address will be specified in the
outgoing e-mail messages sent by the
logger
SENDER_NAME
string
NONE
Sender Name will be specified in the
outgoing e-mail messages
RETRY_DELAY_S 10-86400
30
Retry delay for unsuccessful message
sending attempt
Table 9: DT80 PROFILE Details
