Facelook X1 User’s Manual
2. INSTALLATION AND OPERATION
2.1 WALL-MOUNT INSTALLATION
2.1.1 INSTALLATION AND FIXING
Release the 2 screws and take out the wall bracket from device.
Check the installation height of the face recognition monitor. It is recommended to fix
the bracket on the wall about 1.5m height.
Carefully align and push the main unit into the bracket mounted on the wall.
Align the bracket holes and gently slide it down tightly. After connecting the wires, fix
the bottom cover with screws.
The instruction is shown as below diagram:
