DR (FLEX)
Date: 01-01-2016
Version: 06
USERS MANUAL
Page 16
Rotate the two grips to the outside of the
disc
Lock the grips by pushing it into the disc
Rotate disc counter clockwise
Weight of disc is approx. 13 kg (29 lbs)
Pull disc towards you
Place disc with other divisions in opposite
direction as well the other press ring
Do not forget to use other rounding
plates as well
