8 EXCHANGING DIVIDING DISCS (ONLY MODEL DR-FLEX)
Always turn the main switch to “0” (=off)
before.
• Remove front cover and rear cover
• Pull locking pin
• Turn de dividing disc up by pulling up the knife
release lever (see position 1)
• Put locking pin together with extra supplied rubber
ring into the hole of the rotated part to keep the
disc up.
• Remove the pressing ring by rotating it
counter clockwise
• Remove the two locking pins on top of the
disc.
