10.2 Cleaning of the dividing head and knife crown
• Remove covers (see position 1)
• Turn the weight control bar to its maximum
(see figure position 2)
• Remove locking pin (see position 3)
Be aware the pressing handle will rotate
backwards if the dividing disc will tilt towards.
• Turn de dividing disc up by pulling up the knife
release lever (see position 1)
• Put locking pin together with extra supplied rubber
ring into the hole of the rotated part to keep the disc
up.
• Remove the pressing ring (see position 1)
