Davis Instruments Vantage Pro2 User Manual

Console Location
8
Wall Mounting
The console mounts to the wall using two keyholes located on the back of the case.
To mount the console on a wall:
1. Use a ruler to mark two mounting hole positions on the wall 8 inches (203 mm)
apart.
This is a representation for the mounting hole positions. This template is not true to size.
If installing a cabled Vantage Pro2 console with sensor cable running inside the
wall, mount the console over an empty switch box.
2. Use a drill and a 3/32 or 7/64''(2.5 mm) drill bit to drill two pilot holes for the
screws.
3. Using a screwdriver, drive the two #6 x 1'' pan head self-threading screws into the
wall. Leave at least 1/8'' (3 mm) between the wall and the heads of the screws.
4. If the kickstand has been pulled out from the case, push it back into its upright and
locked position.
5. Guide the two keyholes on the back of the console over the two screws.
Drill two 3/32" or 7/64" (2.4 to 2.8mm) holes
8" (203mm) apart for the #6 x 1" mounting screws.
8" (203mm)

Davis Instruments Vantage Pro2 Specifications

General

Update Interval	2.5 seconds
Wind Direction Resolution	1°
Wind Direction Range	0 to 360°
Rain Collector	Self-emptying tipping bucket
UV Index Range	0 to 16
Solar Radiation Range	0 to 1800 W/m²
Console Display	LCD with backlight
Wireless Transmission Range	1000 feet (300 meters) line of sight
Temperature Range	-40 to 150 °F (-40 to 65 °C)
Humidity Range	1 to 100%
Barometric Pressure Range	16.00 to 32.50 inHg (540 to 1100 hPa)
Wind Speed Range	0 to 200 mph (0 to 322 km/h)
Rain Collector Size	0.01 inch (0.2 mm) resolution
Rain Measurement Accuracy	±4% at rates up to 2 in/hr (50 mm/hr)
Power Supply	Solar-powered with battery backup
Console Power Supply	AC adapter or 3 C batteries
