Davis Instruments Vantage Pro2 User Manual

Console Maintenance
40
Console Maintenance
Changing Batteries
Use this procedure to change console batteries without losing any stored weather data
or console configuration settings.
1. Plug in the AC adapter or, if the AC adapter is not present, enter Setup Mode by
pressing DONE and then the - key.
Note: If you cannot plug in the AC Adapter, entering Setup Mode makes sure the station isn’t writing
any data to memory when power is removed and avoids data loss.
2. Remove the battery cover located on the back of the console by pressing down on
the two latches at the top of the cover.
3. Place the console face down on a flat, firm surface.
4. Insert a fingertip between the two exposed batteries then press the middle battery
down toward the notch (toward the “hidden” battery). This will relieve tension on
the first battery and allow you to remove it.
5. Remove the old batteries and install the new batteries.
6. Replace the battery cover and remove the AC power adapter, if used.
7. Check and set date and time if power was lost.
One Year Limited Warranty
For details on our warranty policy, please refer to the Maintenance, Service, and Repair
Information brochure included with your station.

Davis Instruments Vantage Pro2 Specifications

General

Update Interval	2.5 seconds
Wind Direction Resolution	1°
Wind Direction Range	0 to 360°
Rain Collector	Self-emptying tipping bucket
UV Index Range	0 to 16
Solar Radiation Range	0 to 1800 W/m²
Console Display	LCD with backlight
Wireless Transmission Range	1000 feet (300 meters) line of sight
Temperature Range	-40 to 150 °F (-40 to 65 °C)
Humidity Range	1 to 100%
Barometric Pressure Range	16.00 to 32.50 inHg (540 to 1100 hPa)
Wind Speed Range	0 to 200 mph (0 to 322 km/h)
Rain Collector Size	0.01 inch (0.2 mm) resolution
Rain Measurement Accuracy	±4% at rates up to 2 in/hr (50 mm/hr)
Power Supply	Solar-powered with battery backup
Console Power Supply	AC adapter or 3 C batteries
