47
Appendix B
Specifications
See complete specifications for your Vantage Pro2 Station at our website:
www.davisnet.com.
Console Specifications
Console Operating Temperature . . . . . . . . +32° to +140°F (0° to +60°C)
Non-operating Temperature . . . . . . . . . . . +14° to +158°F (-10° to +70°C)
Console Current Draw . . . . . . . . . . . . . . . Wireless: 0.9 mA average, 30 mA
peak, (add 120 mA for display lamps,
add 0.125 mA for each optional
transmitter station received by con-
sole) at 4 to 6 VDC
Cabled: 10 mA (average), 15 mA
(peak) (+80 mA for illuminated dis-
play) at 4 to 6 VDC
Power Adapter . . . . . . . . . . . . . . . . . . . . . 5 VDC, 300 mA, regulated
Battery Backup . . . . . . . . . . . . . . . . . . . . 3 C-cells
Battery Life (no AC power) . . . . . . . . . . . . Wireless: up to 9 months; (Cabled:
approximately 1 month)
Connectors . . . . . . . . . . . . . . . . . . . . . . . . Modular RJ-11
Housing Material. . . . . . . . . . . . . . . . . . . . UV-resistant ABS plastic
Console Display Type . . . . . . . . . . . . . . . . LCD Transflective
Display Backlight . . . . . . . . . . . . . . . . . . . LEDs
Dimensions:
Console (with antenna) . . . . . . . . . . . 10.625" x 6.125" x 1.625" (270 mm x
156 mm x 41 mm)
Console (no antenna) . . . . . . . . . . . . 9.625" x 6.125" x 1.625" (244 mm x
156 mm x 41 mm)
Display . . . . . . . . . . . . . . . . . . . . . . . 5.94" x 3.375" (151 mm x 86 mm)
Weight (with batteries). . . . . . . . . . . . 1.88 lbs. (.85 kg)
Wireless Communication Specifications
Transmit/Receive Frequency
US Models: . . . . . . . . . . . . . . . . . . . 902 - 928 MHz FHSS
Overseas Models: . . . . . . . . . . . . . . . 868.0 - 868.6 MHz FHSS
ID Codes Available . . . . . . . . . . . . . . . . . . 8
Output Power . . . . . . . . . . . . . . . . . . . . . . 902 - 928 MHz FHSS: FCC-certified
low power, less than 8 mW, no li-
cense required
868.0 -868.6 MHz: CE-certified, less
than 8 mW, no license required
Range
Line of Sight . . . . . . . . . . . . . . . . . . . up to 1000 feet (300 m)
Through Walls . . . . . . . . . . . . . . . . . . 200 to 400 feet (75 to 120 m)

Other manuals for Davis Instruments Vantage Pro2

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Davis Instruments Vantage Pro2 and is the answer not in the manual?

Davis Instruments Vantage Pro2 Specifications

General IconGeneral
Update Interval2.5 seconds
Wind Direction Resolution
Wind Direction Range0 to 360°
Rain CollectorSelf-emptying tipping bucket
UV Index Range0 to 16
Solar Radiation Range0 to 1800 W/m²
Console DisplayLCD with backlight
Wireless Transmission Range1000 feet (300 meters) line of sight
Temperature Range-40 to 150 °F (-40 to 65 °C)
Humidity Range1 to 100%
Barometric Pressure Range16.00 to 32.50 inHg (540 to 1100 hPa)
Wind Speed Range0 to 200 mph (0 to 322 km/h)
Rain Collector Size0.01 inch (0.2 mm) resolution
Rain Measurement Accuracy±4% at rates up to 2 in/hr (50 mm/hr)
Power SupplySolar-powered with battery backup
Console Power SupplyAC adapter or 3 C batteries
