Davis Instruments Vantage Pro2 User Manual

52
If the transmitter ID being repeated is displayed and an “X” flashes in the bottom
right corner of the ticker tape, the transmitter is being repeated and received by the
console successfully.
The repeater’s information also displays at the bottom of the console’s diagnostics
screens.
Clearing Repeater ID
If a repeater ID is being displayed in Screen 2 and you are not using a repeater with the
selected station, you must turn off the repeater function to receive station information
successfully.
In Setup Screen 2:
Press 2ND and then press WIND repeatedly so that the console cycles through the list
of repeater IDs (Repeaters A-H) until the section where the repeater ID was displayed
is blank. Press DONE to continue to the next screen or press and hold DONE to return
to the Current Weather Mode.

Davis Instruments Vantage Pro2 Specifications

General

Update Interval	2.5 seconds
Wind Direction Resolution	1°
Wind Direction Range	0 to 360°
Rain Collector	Self-emptying tipping bucket
UV Index Range	0 to 16
Solar Radiation Range	0 to 1800 W/m²
Console Display	LCD with backlight
Wireless Transmission Range	1000 feet (300 meters) line of sight
Temperature Range	-40 to 150 °F (-40 to 65 °C)
Humidity Range	1 to 100%
Barometric Pressure Range	16.00 to 32.50 inHg (540 to 1100 hPa)
Wind Speed Range	0 to 200 mph (0 to 322 km/h)
Rain Collector Size	0.01 inch (0.2 mm) resolution
Rain Measurement Accuracy	±4% at rates up to 2 in/hr (50 mm/hr)
Power Supply	Solar-powered with battery backup
Console Power Supply	AC adapter or 3 C batteries
