GoIP User Manual
http://www.dbltek.com
This page defines how incoming calls to each GSM channel are handled. GSM incoming calls can either be
answered and prompted for second dial or forwarded to a phone extension or IVR in the VoIP network
connected. The parameters in the Call In Page are divided into two sections. The top section contact the
parameters that are applicable to all channels and the bottom section are for each channel individually.
1. The CID Forward Mode is applicable intended to forward the GSM caller ID to VoIP and for all channels.
Please refer to Appendix E for more details'
2. The Call IN via GSM parameter must be enabled in order to receive GSM incoming calls.
3. The Hunt Group Mode is use to simulate "Call Center" operation where a single GSM number is used for
all incoming calls. To enable this function, set the Hunt Group mode of one GSM channel to "Host" and
all other channels to "Client". Please do not set more than one channel to Host as it may cause the Hunt
Group mode not to function properly. In addition, the GSM Forwarding for all "Client" channels must be
4. The Call IN Auth is used authenticate the incoming calls. Calls can be accepted or rejected based on this
setting and the corresponding White list or Black list.
5. The Auto Incoming Call Block is used to block an incoming call when the same number is called
consecutively for more than the limit defined. Customer has requested this feature to block test calls
that are sent by the carrier.
6. The *Auto Config. Other Line button is provide to facilitate the programming of each channel. After the
parameters for CH1 are set, clicking this button automatically duplicates the CH1 settings to all other
The parameters defined in this section are described in details in the Table below.
Parameter Description Default Value
1. CID Forward Mode This specifies the method used to transmit an incoming GSM caller ID to VoIP. Enabled
