The Input Router lets you select from any of the input sources and adjust the Master Gain. Pink Noise
On/Off and Gain are also available in this module.
Selected Source Switch
Allows selection between the input Sources (Analog 1-4, AES/EBU 1-4, CobraNet 1-4).
Pink Noise Gain fader
Provides Gain control of the internal Pink Noise source (-20 to +20 dB).
Pink Noise On/Off switch
Turns the pink noise on or off
Master Gain fader
Provides Gain control for the Router module (–inf to +20dB).
6.2 - Input Router
DriveRack
®
DriveRack
®
4800/4820 User Manual
