dbx DriveRack 4820 - Output Processing Details

®
Each output DSP channel can be configured with either a Mixer or Router. The Output Mixer lets you
mix between signals coming from the input DSP channels. Master Gain and Muting of this Mixer is also
available.
Channels A-D
Provides gain control for each of the input channels (–inf to +20dB).
Master Gain fader
Provides Gain control for the Mixer module (–inf to +20dB).
Master Mute switch
Allows output muting of the Mixer module.
6.6 - Output Mixer
