dbx DriveRack 4820 - Output Router

Detailed Parameters
®
Section 6
The Output Router lets you select from any of the input channels, adjust the Master Gain and Mute the
output.
Selected Source Switch
Allows selection between the input channels (Channels A-D).
Master Gain fader
Provides Gain control for the Router module (–inf to +20dB).
Master Mute switch
Provides Mute control for the Router module.
6.7 - Output Router
