Input Insert Processing: Two selectable Insert Processing blocks per input
Type: Noise Gate, Compressor, Auto Gain Control, De-Esser, Sub-Harmonic Synth, Advanced Feedback
Suppression
Input Delay Length: Up to 682 mSec available
Routing/Mixing: 4-input mixer available at each output allowing any input to be sent or mixed to any output
Output Insert Processing: Two selectable Insert Processing blocks per output
Type: Noise Gate, AutoWarmth
®
, Compressor, Auto Gain Control, Peak Limiter, Sub-Harmonic Synth,
Advanced Feedback Suppression
X-Over Filter Configs: 1x1, 1x2, 1x3, 1x4, 1x5, 1x6, 1x7, 1x8, 2x2, 2x3, 2x4
2x5, 2x6, 2x7, 2x8, 3x3, 3x4, 3x6, 3x7, 4x4, 4x5, 4x8
Types: Bessel 6, 12, 18, and 24 dB per Octave
Butterworth 6, 12, 18, and 24 dB per Octave
Linkwitz-Riley 12, 24, 36, and 48 dB per Octave
Polarity: Positive and Negative
Phase Control: 0 to -180 degrees in 5 degree increments
Output Delay Length: 1365 mSec shared between the outputs
Miscellaneous:
I/O Transformers: Optional, Jensen
®
JT-11 and JT-123-dbx
CobraNet
®
I/O: Optional
Control: Ethernet, RS-232, Optional dbx ZC Wall Panels
Power Requirements: 100V to 240V 50/60Hz, 45 Watts
Dimensions: 3.5” x 19” x 12.15”
Weight: 11 lbs. (14 lbs. w/audio transformers)
Shipping Weight: 12.5 lbs. (15.5 lbs. w/audio transformers)
Appendix
69
