dbx DriveRack 4820 - Network Setup and Troubleshooting; Zone Controller Wiring and Installation

DriveRack
®
4800/4820 User Manual
®
Appendix
75
Diagram A
Diagram B
Diagram C
RJ-45
(8-Position)
RJ-45
(8-Position)
Orange
White/Blue
Green
Blue
White/Brown
Brown
-VREF
-Zone 1
-Zone 2
-Zone 4
-Zone 3
-Zone 5
-Zone 6
-GND
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
White/Green
White/Orange
Cable Specification: EIA/TIA 568A Standard (pin to pin) 24 AWG wire
