Specifications
ANALOG INPUTS
Number of Inputs: 3 analog line inputs/2 AES digital inputs (shared connectors), 1 RTA mic input
Connectors: 3 female XLRs (2 selectable between analog/AES digital audio formats), 1 female
XLR RTA mic input
Type: Electronically balanced/RF filtered
Impedance: > 30 kΩ, balanced line to line
Max Input Level (line inputs): > +28 dBu, balanced, ≤1% THD
CMRR: > 50 dB @ 1 kHz
RTA Mic Preamp Phantom Power: +48 VDC
ANALOG OUTPUTS
Number of Outputs: 6 line outputs
Connectors: Male XLR
Type: Electronically balanced, RF filtered
Impedance: 120 Ω, balanced line to line
Max Output Level: +22 dBu, balanced, ≤1% THD
Alignment Delay: Up to 1000 ms per output channel
A/D PERFORMANCE
A/D Converter: 24-bit with dbx Type IV™ Conversion System
A/D Dynamic Range: 117 dB A-weighted, 114 dB unweighted, 22 kHz BW
Type IV Dynamic Range: 129 dB with transient material, A-weighted, 22 kHz BW;
126 dB with transient material, unweighted, 22 kHz BW;
121 dB typical with program material, A-weighted, 22 kHz BW
D/A PERFORMANCE
D/A Converter: 24-bit
D/A Dynamic Range: 116 dB A-weighted, 113 dB unweighted, 22 kHz BW
SYSTEM PERFORMANCE
Internal Processing Wordlength: 32-bit floating point
Supported Sample Rates: 48/96 kHz (32-192 kHz using sample rate conversion)
Dynamic Range: 114 dB A-weighted
110 dB unweighted
THD+Noise: 0.0025% typical at +4 dBu, 1 kHz, 0 dB input gain
Frequency Response: 20 Hz – 20 kHz, +0 /- 0.5 dB
Interchannel Crosstalk: < -97 dB, -105 dB typical 20-20 kHz, +4 dBu, all channels measured
Latency: Analog input to output: 2.57 ms (48 kHz), 2.28 ms (96 kHz)
Digital AES input to output: 2.31 ms (48 kHz), 2.15 ms (96 kHz)
Operating Temperature: 0º to 40º C (32º to 104º F)
BLU LINK AUDIO
Connectors: 2 x RJ-45 Ethernet connectors
Maximum Nodes: Up to 60 devices
Maximum Cable Length: 100m/328ft on Category 5e or higher cable between devices
Latency: 11/Fs [0.23ms@48k, 0.11ms@96k]
Pass Through Latency: 4/Fs [0.08ms@48k, 0.04ms@96k]
