DCN S5750E Series User Manual

S5750E Series Installation Guide Chapter 1 Introduction
1-5
MGMT
On (Green)
Network management port 10M / 100M
/ 1G is linking
Off
Network management port is not
linking
Blink
Data forwarding
Table 1-2 S5750E-52X-P-SI(R2.0) System LEDs
1.4.5 Interface Description of Front Panel
Port mode
Spec
RJ-45 port
 10/100/1000Mbps auto negotiation
 MDI/MDI-X cable mode auto negotiation
 5 kinds of UTP: 100 m
SFP
 SFP-SX-L transceiver
1000Base-SX SFP(850nm,MMF,550m)
 SFP-LX-L transceiver
1000Base-LX SFP(1310nm, SMF, 10km or
MMF, 550m)
 SFP-LX-20-L transceiver
1310nm lightwave, 9/125um single mode
fiber: 20km
 SFP-LX-40 transceiver
9/125um single mode fiber: 40km
 SFP-LH-70-L transceiver
9/125um single mode fiber: 70km
 SFP-LH-120-L transceiver
9/125um single mode fiber: 120km
SFP+
 SFPX-SR transceiver
10GBase-SR SFP+ (850nm,MMF,550m)
 SFPX-LR transceiver
10GBase-LR SFP+(1310nm, SMF, 10km)
DAC-SFPX
 DAC-SFPX-3M
 DAC-SFPX-5M
AOC-SFPX
 AOC-SFPX-5M
 AOC-SFPX-10M
Table 1-3 interface descriptions
