OPERATING PARAMETERS
Operationmodeselectionofthewarninglightoutput: If=0“warninglight”(outputalwaysONwhenthegateisopen,OFFafteraclosingoperation), If=1“flashingwarninglight”(slowintermittentoutputduringopeningandfastwhileclosing,alwaysONatgateopened,alwaysOFFatthe
endofaclosingoperationonly), If>1“courtesylight”(outputONduringeachmovement,OFFwhenthemotorstops,afterthesettingdelay)
•000:“fixwarninglight” •001:“flashingwarninglight”(only for 24V) •>001:“courtesylight”offdelay (1sec………………255sec)
Unusedparameter “softstart”function:motorsaccelerategraduallyuntiltheyreachthesetspeed,avoidingsuddendepartures. Warning (230V only):Foroperatorswithoutencoder,theparameterwillbeingnored.
•000:“softstart”deactivated •001:“softstart”activated •002:“longsoftstart”activated
Adjusttheinversiononobstacleperiod(detectedbyinternalanti-crushingsensororbythesafetyinputwhenactivated):If=0itmakesa
completeinversion,if>0indicatestheduration(inseconds)oftherun,afterinversionresultingfrom detection of an obstacleduringthe
opening.
•000:inversionecompletasuostacolo •>000:duratadell’inversionesuostacolo (1sec……………..10sec)
Adjusttheinversiononobstacleperiod(detectedbyinternalanti-crushingsensororbythesafetyinputwhenactivated):If=0itmakesa
completeinversion,if>0indicatestheduration(inseconds)oftherun,afterinversionresultingfromdetectionofanobstacleduringtheclosing.
•000:completereversalonobstacle •>000:durationofreversalonobstacle (1sec……………..10sec)
Facilitationmanualrelease:If≠0,afterdetectingthelockingstop,theenginereversesforabrieftimetoreleasethepressureonit,andthus
facilitatethemanualrelease.Thesetvalueshowsthelengthoftheinversion.If=0functiondisabled
•000:facilitatingreleasedisabled •>000:facilitationactivatedwithreleasetimeequalto: (1x25ms……….................40x25ms)
Unusedparameter Unusedparameter Unusedparameter “Energysaving”mode:If=1after10secofinactivity,thecontrolpanelturnsthe24Voutputsandthedisplayoffthatwillbeturnedonatfirst commandreceived(userecommendedbattery-poweredand/orsolarpanel).
•000:“Energysaving”notactive •001:“Energysaving”active
Electric-lockoutputoperating:If=0“boost”outputforelectric-lockart.110powersupply,If=124VoutputcontrolledbytheELOCK_INinputas
pulsedmode,If=224VoutputcontrolledbytheELOCK_INinputasstep-by-stepmode,If=3electro-brakeoutputfornotself-lockingoperators,
If=424Voutputforelectric-lockpowersupplyviaanexternalrelay,If=524Voutputforelectro-magnetspowersupplyforbarriers,If>524V
outputcontrolledbytheELOCK_INinputastemporizedmode(thesetvalueindicatestheswitch-offdelayinseconds).
•000:“Boost”outputforelectric-lockart.110powersupply •001:“24V pulseoutputmax5W
•002:“24V step-by-stepoutputmax5W •003:“Electric-lockoutputfornotself-lockingoperators •004:“Outputforelectric-lockpowersupplyviaanexternalrelay •005:“outputforelectro-magnetspowersupplyforbarriers •>005:“24V temporizedoutputmax5W (5sec………………255sec)
Rundirectioninversion:If=1automaticallyreversestheoutputsopen/closeoftheoperatorsandanyopening/closinglimitswitchesinputs,
avoidinghavingtomanualchangethewiringwheninstallingtheoperatorinaninvertedposition.
•000:“Standardinstallation” •001:“Invertedinstallation”
Multiplieroperations-counter:Multiplythenumberofoperationsafterwhichthetotaloperations-counterwillbeupdated. Toviewthevalues,refertothesection“Visualisationofinputsandoperations-counterstatus”.
•000:“x100 •001:“x1000 •002:“x10000 •003:“x100000
MaintenanceOperations-counter:if=0resetthecounteranddisablestheinterventionrequest,if>0indicatesthenumberofoperations(x
500)tobemadebeforethecontrolpanelexecutesa4secondadditionalpre-flashtoindicatetheneedofmaintenance. i.g.:IfP064=050,operationsnumber=50x500=25000operations Warning:Beforeyousetanewvalueofthecounter-manoeuvresmaintenance,thesamemustberesetbysettingP065=0andonlylater
P065=“newvalue”.
•000:“RequestMaintenancedisabled •>000:“Numberofoperations(x500)forrequiredmaintenance (1...................................255)
Selectionofoperatingflashinglightoutput:If=0intermittentflashinglightoutput; If=1Fixedflashinglightoutput(forflashinglightswithintermittentinteriorcircuits).
•000:“intermittentflashinglightoutput •001:“fixedflashinglightoutput
