Dean Super Runner Series - Page 34

DEAN MILLIVOLT GAS FRYERS
CHAPTER 2: PARTS LIST
2-11
2.4.2 SR Series, SM35G, SM40G and SM50G Systems (cont.)
ITEM PART # COMPONENT
1 12188-1 Frypot- M/S (After 6/98)- SR38G obsolete
* 12188-2 Frypot- S/S (After 6/98)- SR38G obsolete
* 12082NV Frypot- M/S (P&S Prior to 6/98)- SR38G obsolete
* 12202-1 Frypot- M/S (Japan/Singapore)- SR38G obsolete
* 12202-2 Frypot- S/S (Japan/Singapore)- SR38G obsolete
* 826-1865 Frypot- S/S- SR42G (Began using 1” drain Mar. 2003)
* 826-1871 Frypot- S/S- SR52G, SM50G
* 826-1867 Frypot- S/S- SM35G, SM40G
2 210-5185 Diffuser, Burner Tube- SR38G, SR42G, SM35G, SM40G
* 210-5175 Diffuser, Burner Tube- SM50G
* 210-5216 Diffuser, Burner Tube- SR52G
3 810-2150 Burner, Right- SR52G, SM50G
* 810-2039 Burner, Right- SR38G, SR42G, SM35G, SM40G
4 810-2149 Burner, Center- SR52G, SM50G
* 810-2038 Burner, Center- SR38G, SR42G, SM35G, SM40G
5 810-2151 Burner, Left- SR52G, SM50G
* 810-2037 Burner, Left- SR38G, SR42G, SM35G, SM40G
* 200-1329 Bracket, Burner Mounting- SR52G, SM50G
* 809-0459 Bolts, Burner
5
/
16
" – 18x ¾" Hex Head Washer
* 823-3600 Support Assembly, Burner- SM35G, SM40G (Includes Burner Mounting
Bracket & Heat Shield)
* 200-1129 Shield, Burner Heat- SR42G not used after 12/10/04
* 200-1330 Shield, Burner Heat- SR52G, SM50 and 200-1331
6 200-1615 Bracket, Manifold Mounting- SR52G, SM50G
* 200-1311 Bracket, Manifold Mounting- SR38G, SR42G
7 809-0428 Bolt, ¼" -20 x ½" Hex Head
8 809-0823 Nut, Nylock- ¼" -20
9 813-0705 Plug, Brass- ⅛" Square Head
10
Orifice- Domestic/International
* 810-2048 Orifice, Natural- #39 (2.53 mm)- SR52G, SM50G,
* 810-2132 Orifice, Natural- #37 (2.64 mm)- SR38G
* 810-2040 Orifice, Natural- #35 (2.80 mm)- SR42G, SM35G, SM40G
* 810-3097 Orifice, Natural- #35 (2.80 mm) .125-18 NPT - SR42G built after 4/07
* 810-2497 Orifice, LP- #55 (1.32 mm)- SR52G, SR62G, SM20G, SM50G
* 810-2059 Orifice, LP- #53 (1.51 mm)- SR52G, SM50G,
*` 810-3102 Orifice, LP- #53 (1.51 mm) .125-18 NPT - SR42 built after 4/07
* 810-2063 Orifice, LP- #52 (1.61 mm)- SR38G, SR62 (Australia)
* 810-2064 Orifice, LP- #51 (1.70 mm)- SR42G, SM35G, SM40G
* 810-3099 Orifice, LP- #51 (1.70 mm), .125-18 NPT - SR42G built after 4/07
* 810-2400 Orifice, LP- #16 (.016)- Pilot SR52
*
Orifice- CE Only
* 810-2060 Orifice, G20-G25- (2.40 mm)- All Millivolt Fryers in This Section
* 810-3101 Orifice, G20-G25- (2.40 mm) .125-18 NPT - SR42 built after 4/07
* 810-2059 Orifice, G31- (1.51 mm)- All Millivolt Fryers in This Section
* 810-3102 Orifice, G31- (1.51 mm) .125-18 NPT- SR42 built after 4/07
11 823-3618 Manifold, Gas- SR52G, SM50G
* 810-2034 Manifold, Gas- SR38G, SR42G
* 810-3006 Manifold, Gas- SR42G built after 4/07
* 823-3619 Manifold, Gas- SM35G, SM40G
* Not Illustrated
