DEAN MILLIVOLT GAS FRYERS
CHAPTER 2: PARTS LIST
2-12
2.4.2 SR Series, SM35G, SM40G and SM50G Systems (cont.)
ITEM PART # COMPONENT
Gas Valve and Related Plumbing- SM50G – Plumbing Will Vary From Model to
Model- Use the Following Parts As A Reference When Obtaining Parts For Systems
in This Section Other Than SM50G
12 813-0165 Elbow, Street- ½" NPT 90° BM
13 810-2036 Valve, Gas- Natural, Honeywell- Domestic/International ½” in x ¾” out
* 807-1603 Valve, Gas- Natural, Honeywell- ½” in x ½” out Started using Feb. 2003
* 807-3648 Valve, Gas- Natural, Honeywell- ¾” in x ¾” out Started using Feb. 2003 Export
* 807-3645 Valve, Gas- Natural, Robertshaw- ½” in x ¾” out
* 807-3549 Valve, Gas- LP, Honeywell- Domestic/International
* 807-1604 Valve, Gas- LP, Honeywell- ½” in x ½” out Started using Feb. 2003
* 807-3553 Valve, Gas- LP, Honeywell- ¾” in x ¾” out
* 810-1155 CE Adaptor Kit, Honeywell Valve
* 807-2122 Valve, Gas- Natural, Honeywell- CE Only
* 807-2121 Valve, Gas- LP, Honeywell- CE Only
* 807-4137 Valve, Gas- Natural, Honeywell-Australia
* 807-4138 Valve, Gas- LP, Honeywell- Australia
* 807-1846 Valve, Kit – Natural to Propane Conversion
14 813-0418 Nipple, ½” NPT x 17" BM- SM50G
* 813-0670 Nipple, ½” NPT x 19" BM (Measure To Confirm Length)
* 813-0585 Nipple, ½” NPT x 20-½" BM (Measure To Confirm Length)
* 813-0737 Nipple, ½” NPT x 21" BM (Measure To Confirm Length)
15 813-0174 Union- ¾" NPT BM
16 813-0254 Nipple, ¾” NPT x 3" BM- SM50G
17 813-0066 Elbow- ¾” NPT 90° BM
18 813-0112 Nipple, ¾” NPT x 2" BM- SM50G
19 809-0805 Bolt, ¼”-20 x ½" Hex Head
20 810-2043 Clamp, Pipe- ½"
* 200-1450 Bracket, Gas-Supply Clamp Support (UFF-Equipped Systems)
21 813-0031 Bushing, ¾” NPT x ½” NPT BM
22 810-0703 Gas Line, Pilot Supply- ¼” x 17-½" (For CE use 810-1172 23” or 810-2602 25”)
23 810-2033 Thermopile- Non-CE
* 807-3565 Thermopile- CE Only ( Thermocouple 810-1152)
24 810-2032 Burner, Pilot- Natural (Use 106-0692SP for Assembly. Includes item 22, 23 and 24)
* 810-2155 Burner, Pilot- LP
25 106-1742SP
Flue Assembly- SR52G, SM50G
* 200-2872 Shield, Flue Heat- SR52G, SM50G
* 200-1343 Front, Flue Box- SR52G, SM50G
* 200-1350 Rear, Flue Box- SR52G, SM50G
* 12203
Flue Assembly- SR38G
* 12-0363 Shield, Flue Heat- SR38G obsolete
* 12-0362 Front, Flue Box- SR38G obsolete
* 12-0361 Rear, Flue Box- SR38G obsolete
* 106-0696SP
Flue Assembly- SR42G
* 200-1304 Front, Flue Box- SR42G
* 200-1303 Rear, Flue Box- SR42G
* 106-0954SP
Flue Assembly- SM35G, SM40G
* 200-1690 Shield, Flue Heat- SM35G
* 200-1701 Front, Flue Box- SM35G
* 200-1678 Rear, Flue Box- SM35G
* 449-41001 Garland SM50 Drop In Assembly- Natural
* 449-4100001 Garland SM50 Drop In Assembly- Propane
* Not Illustrated
