DEAN MILLIVOLT GAS FRYERS
CHAPTER 2: PARTS LIST
2-21
2.6.1 Oil Return Manifold Components; Fryers with 1½” Drains (cont.)
ITEM PART # COMPONENT
13 813-0673 Nipple, ½” x 8-½" NPT BM
14 810-2125 Oil Return Valve, ⅜"
* 810-0051 Coupling, ½” NPT x 1-
7
/
16
” to adapt return hose to valve
* 200-1143 Retainer, Oil Return Valve Nut
* 809-0877 Nut, Oil Return Valve
15 813-0006 Bushing, Hex- ½” x ⅜" NPT BM
16 813-0625 Nipple, ⅜" x Close NPT BM
17 813-0165 Elbow, Street- ½” x ½" NPT 90° BM
18 813-0634 Elbow, ½” x ⅜" NPT 90° BM
19 813-0062 Elbow, ½" NPT 90° BM
* 106-2568SP Wash Down Hose and Nozzle Assembly
* Not Illustrated
