Page: 17
4.4 Specification OMD-24 A
Range:
0 – 30 ppm, Trend indication 50 ppm
Accuracy:
According IMO MEPC. 107(49)
Linearity:
0 – 30 ppm better than ± 2 %
Display:
Yellow Graphic Display
Power Supply:
24 V AC or DC ± 10 %
Consumption:
< 5 VA
Alarm Points 1 + 2:
Adjustable between 1 – 15 ppm*
(Works adjustment 15 ppm)
Alarm 1 Operating Delay:
(for annunciation purpose)
Adjustable between 1 – 540 sec.
(Works adjustment 2 sec.)
Alarm 2 Operating Delay:
(for control purposes)
Adjustable between 1 – 10 sec.
(Works adjustment 10 sec.)
Alarm Indication:
(Alarm 1, 2, System Fault)
Red LEDs
Alarm Contact Rating:
(Alarm 1, 2)
Potential free 1 pole change over contacts,
3 A / 240 V
Output Signal:
0 – 20 mA or 4 – 20 mA selectable, active
current loop, ext. Load < 150 
Sample/ Fresh Water Pressure:
< 6 bar
Sample Flow:
Approx. 2 l/min
Sample Water Temperature:
+ 1 to + 65° C
Ambient Temperature:
+ 1 to + 55° C
Roll:
Up to 45°
Size:
Computer Unit
Automatic Cleaning Device
Measuring Cell
185 mm W x 210 mm H x 65 mm D
140 mm W x 240 mm H x 120 mm D
140 mm W x 225 mm H x 65 mm D
Distance Computer Unit to
Measuring Cell:
Up to 0.5 m
Option: up to 5 m upon request
Weight:
3.5 Kg
Degree of Protection:
IP 65
Pipe Connections:
R ¼" Female
 Technical specifications are subject to change without notification.
*By request the alarm set point can be set to 5 ppm max.
