Defiant THD-1000 - Page 21

21 HOMEDEPOT.COM
Please contact 844-212-0200 for further assistance.
Mounting Template
*For details please refer to user guide installation section.
Mount tamperproof magnet here
1
2
3
84mm
(3.31inch)
16mm
(0.63inch)
16mm
(0.63inch)
43mm
(1.69inch)
43mm
(1.69inch)
36mm
（1.42inch）
