Deif GPC-3 Installation Instructions

5.1.3 Slot #3, digital I/Os (option M12)
Terminal Function Technical data Description
37 Not available
38 Not available
39 Not available
40 Not available
41 Not available
42 Not available
43 Digital input Optocoupler Configurable
44 Digital input Optocoupler Configurable
45 Digital input Optocoupler Configurable
46 Digital input Optocoupler Configurable
47 Digital input Optocoupler Configurable
48 Digital input Optocoupler Configurable
49 Digital input Optocoupler Configurable
50 Digital input Optocoupler Configurable
51 Digital input Optocoupler Configurable
52 Digital input Optocoupler Configurable
53 Digital input Optocoupler Configurable
54 Digital input Optocoupler Configurable
55 Digital input Optocoupler Configurable
56 Com. Common Common for terminals 43-55
57 NO Relay 57 6 GOV/AVR control or configurable
58 Com. 250 V AC/8 A
59 NO Relay 59 7 GOV/AVR control or configurable
60 Com. 250 V AC/8 A
61 NO Relay 61 8 GOV/AVR control or configurable
62 Com. 250 V AC/8 A
63 NO Relay 63 9 GOV/AVR control or configurable
64 Com. 250 V AC/8 A
GOV control requires option G2.
AVR control requires options G2 and D1.
ML-2 installation instructions 4189340582
UK
I/O lists
DEIF A/S Page 16 of 64

Deif GPC-3 Specifications

General

Model	GPC-3
Protection front	IP65
Power consumption	10 W
Operating temperature	-20°C to +55°C
Storage temperature	-40°C to 85°C
Communication	Ethernet
Display	Graphical LCD
Dimensions	144 x 144 x 115 mm
