MIB
Inst
allati
on Instruc
tions
and Reference Handbook
DEIF A/S
Page 13 of 50
Communication terminals (MIB 7000C only
)
MIB 7000C
Terminal
number
Description
14
A (Data +)
15
B (Data -)
16
S (Data GND)
Digital output terminals (MIB 7020 only
)
MIB 7020
Terminal
number
Description
14
DO1 Digital output
15
DO2 Digital output
16
DOC
Digital output common
12
14
Table of Contents
Default Chapter
2
Table of Contents
2
About this Document
3
General Purpose
3
Intended Users
3
Contents/Overall Structure
3
Warnings and Legal Information
5
Legal Information and Responsibility
5
Electrostatic Discharge Awareness
5
Safety Issues
5
CE-Marking
5
Definitions
6
Product Information
7
Description of Functions
7
Measured and Calculated Values
8
Installation Instructions
10
Electrical Connection
12
Auxiliary Power Supply
14
Measuring Connections
15
Most Used Wiring Method
21
Digital Output (Only MIB 7020)
25
Communication
26
System Parameter Setting
27
Basic Operation
41
Display
41
Display Menus
43
Voltage and Current Data
43
Power Related Data
44
Energy and Running Hour Counters
46
Power Quality Data
47
Statistics Data
