MIB Installation Instructions and Reference Handbook
DEIF A/S
Page 7 of 50
3. Product information
This chapter includes overall product information about the unit.
Description of functions
The multi-instrument MIB is a microprocessor-based measuring unit providing
measurement of all electrical quantities on a 1- or 3-phase electric energy
distribution network. The measurements are shown on the built-in display.
Measures true RMS values on all 1- or 3-phase network topologies with or
without neutral and with both balanced and unbalanced load.
The MIB can replace a large number of standard analogue instruments in all
electrical measuring applications.
It contains all necessary measuring circuits and presents all values on a
display with white backlight. The display has 4 digits resolution for all
measurements. The backlight on-time is selectable.
MIB is a flexible measuring unit that enables the user to easily adapt the
instrument to the individual application. Counter reset and change of the
instrument settings can be password protected.
The product family includes three versions:
• MIB 7000: Basic version
• MIB 7000C: Basic version + communication
• MIB 7020: Basic version + 2 digital outputs
