Deif MTR-3 - Modbus register table (VERSION 2)

MTR-3 Installation Instructions
DEIF A/S Page 40 of 51
VERSION2 (MTR-2-compatible):
Register table for the actual measurements
Parameter
PLC
Modbus reading
Address
Address
Function Type
Start
End
Start
End
Frequency
300050
300051
49
50
04
T5
U1
300058
300059
57
58
04
T5
U2
300060
300061
59
60
04
T5
U3
300062
300063
61
62
04
T5
Uavg (phase to neutral)
300064
300065
63
64
04
T5
ϕ12 (angle between U1 and U2)
300066
300066
65
65
04
T17
ϕ23 (angle between U2 and U3)
300067
300067
66
66
04
T17
ϕ31 (angle between U3 and U1)
300068
300068
67
67
04
T17
U12
300069
300070
68
69
04
T5
U23
300071
300072
70
71
04
T5
U31
300073
300074
72
73
04
T5
Uavg (phase to phase)
300075
300076
74
75
04
T5
I1
300077
300078
76
77
04
T5
I2
300079
300080
78
79
04
T5
I3
300081
300082
80
81
04
T5
INc
300083
300084
82
83
04
T5
INm - reserved
300085
300086
84
85
04
T5
Iavg
300087
300088
86
87
04
T5
Σ I
300089
300090
88
89
04
T5
Active Power Total (Pt)
300091
300092
90
91
04
T6
Active Power Phase L1 (P1)
300093
300094
92
93
04
T6
Active Power Phase L2 (P2)
300095
300096
94
95
04
T6
Active Power Phase L3 (P3)
300097
300098
96
97
04
T6
Reactive Power Total (Qt)
300099
300100
98
99
04
T6
Reactive Power Phase L1 (Q1)
300101
300102
100
101
04
T6
Reactive Power Phase L2 (Q2)
300103
300104
102
103
04
T6
Reactive Power Phase L3 (Q3)
300105
300106
104
105
04
T6
Apparent Power Total (St)
300107
300108
106
107
04
T5
Apparent Power Phase L1 (S1)
300109
300110
108
109
04
T5
Apparent Power Phase L2 (S2)
300111
300112
110
111
04
T5
Apparent Power Phase L3 (S3)
300113
300114
112
113
04
T5
Power Factor Total (PFt)
300115
300116
114
115
04
T7
Power Factor Phase 1 (PF1)
300117
300118
116
117
04
T7
Power Factor Phase 2 (PF2)
300119
300120
118
119
04
T7
Power Factor Phase 3 (PF3)
300121
300122
120
121
04
T7
Power Angle Total
(atan2(Pt,Qt))
300123
300123
122
122
04
T17
ϕ1 (angle between U1 and I1)
300124
300124
123
123
04
T17
ϕ2 (angle between U2 and I2)
300125
300125
124
124
04
T17
ϕ3 (angle between U3 and I3)
300126
300126
125
125
04
T17
Internal Temperature
300127
300127
126
126
04
T17
