MTR-3 Installation Instructions
DEIF A/S Page 46 of 51
Energy Counter 4 Parameter
see Energy Counter 1 Param.
Energy Counter 4 Configuration
see Energy Counter 1 Config.
see Energy Counter 1 Divider
Energy Counter 4 Tarif Selector
see Energy Counter 1 Tarif Selector
Output 1 Number of Breakpoints
Output 1 Lower X Point (X0)
Output 1 Lower Y Point (Y0)
Output 1 X Breakpoint 1 (X1)
Output 1 Y Breakpoint 1 (Y1)
Output 1 X Breakpoint 2 (X2)
Output 1 Y Breakpoint 2 (Y2)
Output 1 X Breakpoint 3 (X3)
Output 1 Y Breakpoint 3 (Y3)
Output 1 X Breakpoint 4 (X4)
Output 1 Y Breakpoint 4 (Y4)
Output 1 X Breakpoint 5 (X5)
Output 1 Y Breakpoint 5 (Y5)
Output 1 X Breakpoint 6 (X6)
Output 1 Y Breakpoint 6 (Y6)
Output 1 Average interval
1 period (0.02 s @50 Hz) default
2 periods (0.04 s @50 Hz)
4 periods (0.08 s @50 Hz)
8 periods (0.16 s @50 Hz)
16 periods (0.32 s @50 Hz)
32 periods (0.64 s @50 Hz)
64 periods (1.28 s @50 Hz)
128 periods (2.56 s @50 Hz)
256 periods (5.12 s @50 Hz)
Thermal function time constant
