MTR-3 Installation Instructions
DEIF A/S Page 47 of 51
Compare time delay
401004
T1
Seconds
Hysteresis
401005
T16
% of compare value, if 0 then % of
nominal value
Reserved
401006
401007
1005
1006
ALARM 1
Alarm 1 parameter
401008
1007
T1
See OutTypes
Alarm 1 function
401009
1008
T1
Bit-1
Reserved: Store into memory (all)
Bit-2
Store into memory (1 per minute)
Bit-3
Activate LED
Bit-4
Activate Alarm Output
Bit-5
Activate Beep Output
Bit-6
Alarm Condition > (< if 0)
Bit-7
Use Thermal function
Alarm 1 compare value
401010
1009
T17
% of parameter value
ALARM 2
401011
401013
1010
1012
See ALARM 1
ALARM 3
401014
401016
1013
1015
See ALARM 1
ALARM 4
401017
401019
1016
1018
See ALARM 1
ALARM 5
401020
401022
1019
1021
See ALARM 1
ALARM 6
401023
401025
1022
1024
See ALARM 1
ALARM 7
401026
401028
1025
1027
See ALARM 1
ALARM 8
401029
401031
1028
1030
See ALARM 1
ALARM GROUP 2 (No. 9…16)
401032
401060
1031
1059
See ALARM GROUP 1
All other Modbus registers are a subject to change. For the latest Modbus register definitions,
go to DEIF’s web page www.deif.com
