Installation Section 2
10 Part Number: 9291545 REV00 11/20
Refrigeration
Custom Model
BTU System Capacity Heat of Rejection
R290 Charge
Base Rail Catch Pan Base Rail Catch Pan
F18DC48P-RCPR 2676 1481 1093 282 330 445 2 x 5.3oz (150g)
F18DC48P-RCPL 2676 1481 1093 282 330 445 2 x 5.3oz (150g)
F18DC72P-RCPR 2676 1826 1341 360 495 668 2 x 5.3oz (150g)
F18DC72P-RCPL 2676 1826 1341 360 495 668 2 x 5.3oz (150g)
F18DC99P-RCPR 2676 2181 1916 475 715 964 2 x 5.3oz (150g)
F18DC99P-RCPL 2676 2181 1916 475 715 964 2 x 5.3oz (150g)
Drain Connections
All models are standard with a condensate evaporator
located behind the louvered door. It is designed to evaporate
the water which condenses on the base’s mullion coils.
Each Makeline has a drain in the catch pan area and in
the top rail area. These drains manifold together in the
mechanical area and can be drained by one common gate
valve.
n
Warning
Moisture collecting from improper drainage can create a
slipper surface on the floor and a hazard to employees.
It is the owner’s responsibility to provide a container or
outlet for drainage.
Leg & Caster Installation
DANGER
Legs or casters must be installed and the legs or casters
must be screwed in completely to prevent bending. When
casters are installed the mass of this unit will allow it to
move uncontrolled on an inclined surface. These units
must be tethered/secured to comply with all applicable
codes.
n
Warning
The unit must be installed in a stable condintion with
the front wheels locked. Locking the front casters after
installation is the owner’s and operator’s responsiblity.
Leveling
After the cabinet has been placed in the desired location,
cabinets with legs must be leveled. Level units from front
to back then side to side. Leveling will insure proper door
operation and removal of condensate. Cabinets with casters
must have the caster brake set so the cabinet cannot move.
Stabilizing
It is very important that all legs are properaly adjusted to
keep the cabinet level ,evenly distribute the weight and to
make sure the unit will not rock, lean or be unstable.
