Delfield F18DC48P-RCPR - Weight of Equipment; Clearance Requirements; Dimensions; Capacity

Installation Section 2
8 Part Number: 9291545 REV00 11/20
Clearance Requirements
DANGER
Minimum clearance requirements are the same for
noncombustible locations as for combustible locations.
The flooring under the appliance must be made of a
noncombustible material.
DANGER
Risk of fire/shock. All minimum clearances must be
maintained. Do not obstruct vents or openings.
All Models Back 6” (15mm)
All Models Louver Side / Non-Louver Side 6” (15mm) / 0” (0cm)
All Models Tops 55” (140cm)
All Models Bottoms 4” (10cm)
• Keep the vents clean and free of obstruction.
• Casters or legs must be used and not removed
Capacity
Custom Model # Of Doors Shelf Area Shelf Max Load Base Volume
F18DC48P-RCPR
1-24” (61cm) 3.40ft2 (3159cm2) 108lbs (49kg) 6.22ft3
(176L)
F18DC48P-RCPL
1-24” (61cm) 3.40ft2 (3159cm2) 108lbs (49kg) 6.22ft3 (176L)
F18DC72P-RCPR
2-27” (69cm) 7.90ft2 (7339cm2) 125lbs (57kg) 13.11ft3 (371L)
F18DC72P-RCPL
2-27” (69cm) 7.90ft2 (7339cm2) 125lbs (57kg) 13.11ft3 (371L)
F18DC99P-RCPR
3-27” (69cm) 11.85ft2 (11009cm2) 125lbs (57kg) 19.69ft3 (558L)
F18DC99P-RCPL
3-27” (69cm) 11.85ft2 (11009cm2) 125lbs (57kg) 19.69ft3 (558L)
Weight Of Equipment
Custom Model Ship Weight
F18DC48P-RCPR 485lbs (220kg)
F18DC48P-RCPL 485lbs (220kg)
F18DC72P-RCPR 718lbs (326kg)
F18DC72P-RCPL 718lbs (326kg)
F18DC99P-RCPR 970lbs (440kg)
F18DC99P-RCPL 970lbs (440kg)
Dimensions
Custom Model
Length Depth Height
F18DC48P-RCPR 48” (122cm) 34” (86cm) 52.38” (133cm)
F18DC48P-RCPL 48” (122cm) 34” (86cm) 52.38” (133cm)
F18DC72P-RCPR 72” (183cm) 34” (86cm) 52.38” (133cm)
F18DC72P-RCPL 72” (183cm) 34” (86cm) 52.38” (133cm)
F18DC99P-RCPR 99” (251cm) 34” (86cm) 52.38” (133cm)
F18DC99P-RCPL 99” (251cm) 34” (86cm) 52.38” (133cm)
