Unpack the (optional) disk-array enclosures
Disk-array enclosures (DAEs) provide additional storage. The types of DAEs available
are:
l
3U 15 disk 3.5" drive DAE
l
2U 25 disk 2.5" drive DAE
DAEs are optional. If you have one or more DAEs in the system, verify that you have
received all of the DAE components, including cables, bezel, rail kit, and mounting
screws.
15-drive DAE container contents
Verifying shipping package contents
Confirm that you received all necessary equipment needed to install the new 15-drive
DAE.
Verify that you received the following:
Component Quantity
Disk-array enclosure (DAE) Front view
Rear view
1
Snap in rail kit
1 (includes 2
rails and 6
screws)
Power cords (AC or DC) AC power cords 2
Unpack your DAE
40 Unity 300/300F, Unity 350F, Unity 380/380F, Unity 400/400F, Unity 450F, Unity 500/500F, Unity 600/600F
and Unity 650F Installation Guide
