h. Fingerprint reader FFC
i. Power button FFC from the system board
Next steps
1. Install the display assembly.
2. Install the heatsink.
3. Install the system fan.
4. Install the memory
5. Install the SSD.
6. Install the WLAN.
7. Install the battery.
8. Install the base cover.
9. Install the SD card.
10. Follow the procedure in after working inside your computer.
Removing the system board - Cirrus Logic audio
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the SD card.
3. Remove the base cover.
4. Remove the battery.
5. Remove the WLAN.
6. Remove the SSD.
7. Remove the hard drive assembly.
8. Remove the memory
9. Remove the system fan.
10. Remove the heatsink.
NOTE: The system board can be removed along with the heat sink.
11. Remove the display assembly.
