Dell 1320c - Color Laser Printer - Replacing the PHD (Print Head Device) Unit

3. Close the side cover.

Replacing the PHD (Print Head Device) Unit
1. Ensure that the printer is turned off.
2. Press the button (right side) and open the front cover.

3. Turn the four PHD lock levers counterclockwise.

4. Pull the PHD unit out of the printer.

