Understanding Tool Box Menus
The Tool Box allows you to view or specify the printer settings. You can also diagnose the printer settings by using the Tool Box.
The Tool Box consists of the Printer Settings Report, Printer Maintenance, and Diagnosis tabs.
Printer Settings Report
Printer Maintenance
Diagnosis
Printer Settings Report
The Printer Settings Report tab includes the Printer Information, Menu Settings, Reports, and TCP/IP Settings pages.
Printer Information
Purpose:
To verify the printer details such as hardware configuration and software version.
Values:
Menu Settings
Purpose:
To display the current settings of the printer.
NOTE: A Password dialog box appears the first time you try to change settings or click a button after starting up the Tool Box. Input the password you
specified in Set Password in the Printer Maintenance tab. The default password is left blank. You can click OK without entering a password to go to the
next step.
NOTE: Values marked by an asterisk (*) are the factory default menu settings.
Displays Dell's service tag number.
Displays the printer's serial number.
Displays the type of printing for the printer. Color Laser is displayed normally.
Displays the printer's asset tag number.
Displays the memory capacity.
Displays the processing speed.
Displays the version of the controller.
Displays the NIC version.
Displays the version of the MCU firmware.
Displays the speed for color printing.
Printing Speed (Monochrome)
Displays the speed for monochrome printing.
