Auger mark
Abnormal noise
Is the error print match with the pattern for the auger
mark?
Yes. Click the Tool Box button.
1. Press the Start button.
2. After you perform the Developer Stir Mode, click the
Tool Box button, and then press Print with A4(1) or
Print with Letter(A). "Printing" appears.
Is the problem recovered?
Yes. The task is complete.
No. Replace the PHD unit. See "Replacing the PHD (Print
Head Device) Unit" and "Installing the PHD Unit".
No. Replace the PHD unit. See "Replacing the PHD (Print
Head Device) Unit" and "Installing the PHD Unit".
Locate the cause of the problem by removing the toner
cartridges, fuser, and PHD unit.
1. Remove the toner cartridges, fuser, and PHD unit. See
"Removing the Used Toner Cartridge", "Removing the
Used Fuser", and "Replacing the PHD (Print Head
Device) Unit".
2. Click the Tool Box button.
3. Press the Start button after selecting Main Motor
Operation Check, Fuser Motor Operation Check, and
Dispense Motor Check to identify the abnormal noise.
Check if the noise from the Play of Sound button is
matched with the abnormal noise.
1. Is the noise from Main Motor Operation Check
matched?
2. Is the noise from Fuser Motor Operation Check
matched?
3. Is the noise from Dispense Motor Check matched?
NOTE: Do not check the operation of the
dispense motor repeatedly.
No. Replace the fuser. See "Removing the Used Fuser" and
"Installing a New Fuser".
4. Is the noise from Fuser Motor Operation Check
matched?
No. Replace the PHD unit. See "Replacing the PHD (Print
Head Device) Unit" and "Installing the PHD Unit".
