Toner smears or print comes off page.
If you are printing on an uneven print surface, change the paper type setting in the printer driver. For example, change the plain paper to thick.
Toner spots appear on the page/printing is blurred.
3. If the print is too light, Select Refresh Mode from the
list. Press the Start(1)-(4) buttons.
CAUTION: Using the Refresh Mode consumes extra toner.
4. After you complete the Refresh Mode, select Chart
Print from the list. Press the Print with A4(3) or Print
with Letter(C) button for 4 Colors Configuration Chart.
"Printing" appears.
Is the problem recovered?
Yes. The task is complete.
No. The PHD unit is old or damaged. Replace the PHD unit.
Try the spare PHD unit, if possible.
1. Replace the PHD unit. See "Replacing the PHD (Print
Head Device) Unit" and "Installing the PHD Unit".
2. After you replace the PHD unit, click the Tool Box
button.
3. Press the Print with A4(3) or Print with Letter(C)
button.
Is the problem recovered?
Yes. The PHD unit is old or damaged. Replace the PHD unit.
1. Press [Printing Preferences], and then click the Paper
Tray tab.
Verify that the correct print media is being used.
1. See "Print Media Sizes and Support."
Try the spare PHD unit, if possible.
1. Replace the PHD unit. See "Replacing the PHD (Print
Head Device) Unit" and "Installing the PHD Unit".
2. After you replace the PHD unit, print paper. "Printing"
appears.
Is the problem recovered?
Yes. The PHD unit is old or damaged. Replace the PHD unit.
Try the spare fuser, if possible.
1. Replace the fuser. See "Removing the Used Fuser"
and "Installing a New Fuser".
2. After you replace the fuser, print paper. "Printing"
appears.
Is the problem recovered?
Yes. The fuser is old or damaged. Replace the fuser.
No. Contact Dell.
