1700 Flat Panel Monitor User’s Guide 1-15
Table 1-5. D-Sub Connector Pin Assignments
Pin No. 15-Pin Side of the Signal Cable
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Red
Green
Blue
GND
DDC Return
GND-R
GND-G
GND-B
Reserved
GND-Sync/Self Test
GND
DDC Data
H-Sync
V-Sync
DDC Clock
Table 1-6. 13W3 Connector Pin Assignments
Pin No. 13W3 Side of the Signal Cable
A1
A2
A3
1
2
3
4
5
6
7
8
9
10
Red
Green
Blue
DDC Clock
NC
Reserved
Serial Data Return
Composite H/V Sync
DDC Data
V-Sync
NC
Reserved
Sync Return
