Dell 5000 - Page 17

2. Drill four holes in the wall that correspond to the holes on the mounting bracket.
3. Place the Embedded Box PC against the wall and align the holes on the mounting brackets with the holes on the wall.
4. Secure the Embedded Box PC to the wall.
NOTE: Torque the screws (M4x6) at 5 to 5.4 kilograms-centimeter (4.3 to 4.7 pounds-inch).
17
