Dell 5000 - Windows 10 Professional

Serial port number Port type Connector Device Node
4 RS232/422/485 DB9 COM4
Embedded Box PC 5000 GPIO In/Out mapping
The GPIOs ports on the Embedded Box PC and Nuvoton NCT6793D uses index/data pair of processor I/O Addresses 2Eh/2Fh to
access NCT6793D.
GPIO 8 Out pin# to NCT6793D pin# map:
0 to 121 (GP00)
1 to 122 (GP01)
2 to 123 (GP02)
3 to 2 (GP03)
4 to 3 (GP04)
5 to 4 (GP05)
6 to 5 (GP06)
7 to 6 (GP07)
8 is GND
GPIO 8 In pin# to NCT6793D pin# map:
0 to 50 (GP60)
1 to 49 (GP61)
2 to 48 (GP62)
3 to 47 (GP63)
4 to 45 (GP64)
5 to 44 (GP65)
6 to 43 (GP66)
7 to 42 (GP67)
8 is GND
Embedded Box PC 5000 IO Module PCIe expansion mapping
The PCIe slots on the Embedded Box PC are driven directly from the host PCIe bus. Since it is a generic PCIe expansion, there are
no PCIe device-specic drivers integrated into the Windows Embedded Standard 7 P/E OS image. If there is a specic PCIe card
used on this slot, contact the Vendor of that PCIe card to verify if they have Windows Embedded Standard 7 P/E drivers.
Windows 10 Professional
Overview
The Embedded Box PC is shipped with Windows 10 Pro. For more information on Windows 10 operating system, see https://
support.microsoft.com/en-us.
28
