Dell 5000 - Windows Embedded Standard 7 P;E

4 to 3 (GP04)
5 to 4 (GP05)
6 to 5 (GP06)
7 to 6 (GP07)
8 is GND
GPIO 8 In pin# to NCT6793D pin# map:
0 to 50 (GP60)
1 to 49 (GP61)
2 to 48 (GP62)
3 to 47 (GP63)
4 to 45 (GP64)
5 to 44 (GP65)
6 to 43 (GP66)
7 to 42 (GP67)
8 is GND
Embedded Box PC 5000 IO Module PCIe expansion mapping
The PCIe slots on the expansion module on the top side of the Embedded Box PC are driven directly from the host PCIe bus. Since
it is generic PCIe expansion, there are no PCIe device-specic drivers integrated into the Windows 7 Professional for Embedded
Systems OS image. If there is specic PCIe card used on this slot, contact the vendor of that PCIe card to verify if they have
Windows 7 Professional for Embedded Systems drivers.
Windows Embedded Standard 7 P/E
Overview
The Embedded Box PC is shipped with Windows Embedded Standard 7 P/E. For more information on Windows 7 operating system,
seehttps://support.microsoft.com/en-us.
Boot up and login
Before conguring the Windows Embedded Standard 7 P/E, connect a keyboard, mouse, and monitor to the Embedded Box PC.
1. Turn on the Embedded Box PC and login to Windows Embedded Standard 7 P/E.
2. Select regional settings.
3. Create a User Account.
4. Read and accept the EULA.
5. Select your preferred settings.
NOTE: Connect to a wireless network if available.
Windows Embedded Standard 7 P/E. basic functions
BIOS update
Download the latest BIOS version from www.dell.com/support. Run the executable in the download package from the local machine.
