Watchdog timer
The watchdog timer for Windows Embedded Standard 7 P/E. is enabled and disabled through the BIOS. Enter the BIOS during boot
by pressing F2. Select System Conguration → Watchdog Timer Support → Enable Watchdog Timer in the BIOS setup program.
The Watchdog Timer feature is used to recover the operating system during the following instances:
• During POST of the computer to ensure that the computer initialization is completed properly by the BIOS/UEFI.
• During the transition from BIOS/UEFI to the operating system through an operating system Watchdog Timer driver.
In both instances, without any human intervention, the Watchdog Timer reacts when the computer is not responding. The Watchdog
Timer is enabled and disabled under the BIOS setting Watchdog Timer.
TPM support
Windows Embedded Standard 7 P/E. supports TPM 1.2. For more information, see https://technet.microsoft.com/en-us/library/
cc749022.aspx.
System shutdown
Click the Start icon, then click Shut down to shut down the Embedded Box PC.
System restart
Click the Start icon, then click right-arrow next to the Shut down button and click Restart.
Conguring LAN/WLAN network
1. Click the Start icon then search for Network.
2. Open Network and Sharing Center.
3. Click Change adapter settings on the left panel.
to congure the LAN on the Embedded Box PC.
Conguring Bluetooth
1. Click the Start icon then search for Bluetooth.
2. Click Change Bluetooth settings.
Conguring WWAN (DW5580) network
NOTE: For instruction on installing the WWAN card and SIM card, see the
Service manual
for your system at
www.dell.com/support. After installing the WWAN module and SIM card:
1. Click the Start icon then search for Network.
2. Open Network and Sharing Center.
3. Click Change adapter settings on the left panel.
4. Locate the WWAN connection and select the entry to connect (or disconnect) to the WWAN module.
Common port mappings
Serial port mapping
The table lists the serial port mapping on the Embedded Box PC 5000, with the Dell factory installed Windows Embedded Standard
7 P/E OS.
Table 3. Serial port mapping
Serial port number Port type Connector Device Node
1 RS232/422/485 DB9 COM1
2 RS232/422/485 DB9 COM2
3 RS232/422/485 DB9 COM3
27
