Dell 5000 - Recommended Drivers and Applications for Embedded Box PC

0 to 121 (GP00)
1 to 122 (GP01)
2 to 123 (GP02)
3 to 2 (GP03)
4 to 3 (GP04)
5 to 4 (GP05)
6 to 5 (GP06)
7 to 6 (GP07)
8 is GND
GPIO 8 In pin# to NCT6793D pin# map:
0 to 50 (GP60)
1 to 49 (GP61)
2 to 48 (GP02)
3 to 47 (GP63)
4 to 45 (GP64)
5 to 44 (GP65)
6 to 43 (GP66)
7 to 42 (GP67)
8 is GND
Embedded Box PC 5000 IO Module PCIe expansion mapping
The PCIe slots on the Embedded Box PC are driven directly from the host PCIe bus. Since it is a generic PCIe expansion, there are
no PCIe device-specic drivers integrated into the Windows 10 IoT Enterprise LTSB 2015 OS image. If there is a specic PCIe card
used on this slot, contact the Vendor of that PCIe card to verify if they have Windows 10 IoT Enterprise LTSB 2015 drivers.
Recommended drivers and applications for Embedded Box PC
Dell recommends installing the drivers and applications required for the Embedded Box PC from www.dell.com/support in the
following sequence:
1. Intel Mobile Chipset Software Installation Utility
2. Critical Microsoft Quick Fix Engineering (QFE)
3. Intel Rapid Storage Technology
4. Graphics
5. Intel Management Technology
6. Audio
7. Integrated wired Network Adapter
8. Wireless Local Network Adapters and Bluetooth
9. USB 3.0
